LOCKFORMER 14 GA PITT
Have one to sell?
ConditionNew
New
The 14, 16 and 18 gauge Pittsburgh rollforming machines have 7 forming stations with two forming positions. One inboard position forms the Pittsburgh lock; and one auxiliary or outboard position has the capability of forming 1 of 8 different profiles depending on which auxiliary roll set is ordered
The Pittsburgh lock revolutionized the HVAC industry in the late 1940’s and is still used today for its strength and ease in assembling ductwork. And for nearly that long, the Lockformer Pittsburgh Lock Roll Formers have set the standard for product quality and performance. The Lockformer Pittsburgh Lock Roll Former | Model 14 has a capacity of 14–16 gauge at a speed of up to 35 feet/minute and features seven (7) forming stations with two (2) forming positions — one inboard forming position forms the Pittsburgh lock and one auxiliary or outboard forming position has the capability of forming 1 of 8 different profiles depending on which auxiliary roll set is ordered.
More Details:
Lockformer Pittsburgh Lock Roll Formers are available in six (6) different configurations (including the Model 14 shown) with varying capacities, configurations, and forming speeds to fit your specific operational needs. All Lockformer Pittsburgh Lock Roll Formers feature:
Industrial motors and high-precision needle-type bearings
Heavy 3/4″ chassis plate
Case-hardened and ground roll shafts
Arc-welded steel stands protected with Lockformer’s top-quality primer and paint finish.
Model - Lockformer Pittsburgh Lock Roll Former | Model 14
Forming Stations - 5
Capacity - 14–16 gauge
Depth of Pocket - 1/2" Uses approximately 1-3/8" of material
Hammer Over-edge Adjustability - 3/8”
Forming Speed - 35 feet per minute
Motor - 5 hp, 230/460 volts, 60 cycle, 3 phase, A.C. 1,800 RPM. Other motors available upon request.
Dimensions - 58.5″L x 24″W x 41″H
Passline - 34”
Shipping Weight - 750 pounds
Additional Rolls
Pittsburgh Lock Rolls
Capacity - 22 - 28 gauge
Material Used - 1” (Approx)
Size - 5/16” Pocket
Double Seam Rolls (TYPE S)
Capacity - 22 - 28 gauge
Material Used - 1-1/8” (Approx)
Size - 3/8” Seam
Double Seam Rolls (TYPE L)
Capacity - 16 - 22 gauge
Material Used - 1-1/4” (Approx)
Size - 7/16” Seam
Drive Cleat Rolls
Capacity - 20 - 26 gauge
Material Used - 2-1/8” (Approx)
Size - 1-1/8” Width
Standing Seam Rolls
Capacity - 16 - 20 gauge
Material Used - 2-1/8” (Approx)
Size - 3/4” Height
Right Angle Flange Rolls
Capacity - 16 - 24 gauge
Material Used - Up to 7/16”
Size - Up to 7/16” Height
Hem Rolls
Capacity - 20 - 24 gauge
Material Used - 1/4”, 3/8”, 1/2” (Approx)
Size - 1/4”, 3/8”, 1/2”
COMBINATION 3 IN 1 ROLLS WITH SPECIAL GUIDE
Right Angle Flange
Capacity - 22 - 26 gauge
Material Used - 1/2” (Approx)
Size - 1/2” Height
Standing Seam
Capacity - 22 - 26 gauge
Material Used - 1-3/4” (Approx)
Size - 5/8” Seam
T-Connection
Capacity - 22 - 26 gauge
Material Used - 1-1/4” (Approx)
Size - 7/16” Seam
