LOCKFORMER 60" x 16 GA Beader
Have one to sell?
New
Beading is a cost-conscious way to stiffen ductwork. It is 5 times faster than cross-braking and uses only one operator. The Lockformer Beader 6016 Beading Roll Former was designed to meet the requirements of SMACNA — producing five (5) beads on 12″ centers and is adjustable to 3/16″ depth.
Lockformer Beader 6016 Beading Roll Former
Model 6016 Beading Roll Former
Capacity 16-30 gauge
Speed 3/4 HP
Motor / Voltage 115/230 volts, 60 cycle, single phase
Dimensions / Weight Max Width: 5', Weight: 1,650 lbs.
With Lockformer quality construction, this machine also features:
Industrial electric motor
Precision bearings
Turned, ground, and polished steel forming rolls and roll shafts
Arc-welded steel stand protected with Lockformer top-quality primer and paint finish
Lubrication fittings are located on each bearing
