The MMB 600 is made for high production rates of large bevels. Our MMB 600 machine is well suited for steel, stainless steel, and other high-strength steel. This stationary beveling machine has five offset contact wheels that are adjustable in height, which gives precise guidance of the workpiece. The machine is right for production and series production environments. Available with backstops and low-speed milling for even tougher materials.
New SAAR MMB 600 Stationary Beveling Machine
Brand - SAAR Hartmetall
Type - Stationary Beveling Machine
Model - MMB 600
Bevel width: (Steel: 1", SS: 3/4", AL: 1-1/8")
Bevel Angle: Variable (25°/55° or 30°/60°)
Material Thickness: .250 - 4"
Spindle RPM: 2000-5500
Automatic feed, manually adjustable, up to 10 ft./min.
Milling Head: 8 square inserts (4 edges) with a set of inserts
Voltage: 480 Volt/ 16A
Power: 8 HP
Weight: 2,140 lbs.
For processing small, medium, and large workpieces
Suitable for aluminum, steel, stainless steel, and high strength steel
Very high bevel quality and high stock removal
Particularly suitable in series production
Feed system uses one feed wheel for small parts and five feed wheels for large parts
Feed rates up to 10 feet/min
Separate variable speed motors for feed rate and milling head, electrically adjustable in height
Chip collection bin included
Precise guidance of the workpiece
Automatic air/oil lubrication system
