| Rect-Cap (H) | 18" | 457.2 mm |
| Rect-Cap (W) | 18" | 457.2 mm |
| Control | CNC | CNC |
CUTTING CAPACITY (ROUND) 18"
CUTTING CAPACITY (RECTANGLE) 20" X 18"
BUNDLE CAPACITY MAXIMUM (WXH) 18.88" X 9.75"
BUNDLE CAPACITY MINIMUM (WXH) 9.38" X 3-1/4"
BANDSAW BLADE SIZE 209" X 1-1/2" X 0.05"
MOTOR HP 10 HP
BAND SPEED 52-430 FPM
BAND TENSION HYDRAULIC
HYDRAULIC SYSTEM --
MOTOR HP 2 HP
RESERVOIR SIZE 22 GALLON
COOLANT SYSTEM TYPE FLOOD COOLANT
MOTOR HP 1/4 HP
RESERVOIR SIZE 29 GALLON
INDEXER ---
LENGTH PER STROKE 19.68"
MAXIMUM INDEX STROKES LENGTH 177"
MAXIMUM INDEX LENGTH 177"
REMNANT LENGTH 7.875" ( NON-BUNDLE)
FLOOR SPACE (L X W X H) 102" X 89" X 71"
MATERIAL PASS LINE HEIGHT 29.5"
MACHINE WEIGHT 6284 LBS
VOLTAGE REQUIRED 230V-60HZ-3PH, WYE CONFIGURATION
TOTAL AMP DRAW (FLA) 33 AMPS
PLC CONTROL
HYDRAULIC RETRACTABLE SHUTTLE VISE
MATERIAL INDEXER
VISE PRESSURE CONTROL
AUTOMATIC CHIP CONVEYOR
COOLANT CONVEYOR
This equipment has been sold. Similar equipment available now is shown below.
