AGIECHARMILLES CUT 200 DEDICATED | Wire EDM

Brand: AgieCharmilles
Model: CUT 200 Dedicated
Type: Wire EDM
Year: 2016

X, Y, Z travel - 350mm x 220mm x 220mm
U, V travel - 350mm x 220mm
Taper angle_height - 25/80°/mm

Work tank door - Swing door
Type of machining - Submerged

Work piece dimensions (W x D x H) - 1000 x 550 x 220mm
Available wire diameters - 0.30 - 0.15mm
Max. work piece weight - 750kg
Available wire diameters - 0.10mm

Permissible weights and types of spools (ISO)
1.6 (K100) - 8 (K160)kg
CC high speed generator
Min. finishing 0.1μm Ra
Large Spool………16 (K200), 25 (K250)kg

HOURS:
Run Time: VERY LOW 23 Hours!

Approximate Machine Dimensions: 2030mm W x 2850mm D x 2200mm H
Estimated Weight: 3500kg (7,700 lbs)

The CUT 200 Dedicated features a built-in, A/B tilt/rotary table to easily cut complex components using C-axis rotation and +/- 20- degree B-axis tilt!

TERMS:
Location Michigan USA - “AS-IS, WHERE-IS” off seller’s floor, Full Payment due prior to shipment. Seller will prep for shipment, buyer pays for removal. Immediate availability, subject to prior sale. Under power and available for in-person inspection. All specifications are assumed to be correct but must be confirmed by the purchasing entity.
