The TENNSMITH SBS12614 is a 10-foot (126-inch) capacity CNC sheet metal folder, handling up to 14 gauge mild steel and 16 gauge stainless steel, featuring a fast twin-motor drive for its bending beam, a 7-inch clamping beam opening, 3-point crowning, and a fully CNC-controlled backgauge for high accuracy in heavy-duty bending operations.
Brand – TENNSMITH
Model – SBS12614
Type – Folding Machines
Capacity – Mild Steel 14 Gauge
Capacity – Stainless Steel 16 Gauge
Bending Length 126″
Bending Bars Standard 1″ 7/16″
Crowning of the Folding Beam 5-Point 0”- 0.030” Adjustment
Folding Beam Adjustment 1″
Folding Beam Speed 80° per second
Back Gauge Speed (0.375” to 41”) 5 Seconds
Clamping Beam Opening Height 7″
Bending Beam Motor 2 + 2 HP
Working Height 34″
Dimensions 180″L x 96″w x 72″H
Weight 9020 (LBS)
TERMS:
Location Hayward, CA - “AS-IS, WHERE-IS” off seller’s floor, Full Payment due prior to shipment.Buyer pays for removal. Immediate availability, subject to prior sale. Under power and available for in-person inspection. All specifications are assumed to be correct but must be confirmed by the purchasing entity.
