BIESSE AKRON 1430A EDGEBANDER.
-- Specifications:
0.4 - 3 mm Thickness coil edgebanding, .0.4 - 12 mm thickness of strips (HPL, veneer, solid wood strips).
-- Panel thickness minimum 10 mm and 60 mm maximum. Minimum panel length 140 mm. (5.5"), minimum panel width 85 mm (3.3).
-- Automatic strip & coil feed magazine with 3 mm PVC guillotine.
-- Hot Melt glue system, 10 Minute heat-up time.
-- 1" Dia. Glue applicator roller; pressure section with (1) large dia. "non-stick" coated drive roller.
Workstations:
-- Front & Rear End Trims: (0.33 HP - 12,000 RPM motors), motors travel on (2) straight slides and pneumatic tilt 0° - 25° on horizontal plane.
-- Top & Bottom Rough Trims with motors (0.75 HP - 12,000 RPM motors), digital readouts for easy setup.
-- Top & Bottom Fine Trims with motors (0.5 HP - 12,000 RPM).
-- Top & Bottom Profile Scrapers with digital readouts for horizontal adjustments.
-- Top & Bottom Glue Scrapers, digital readout for horizontal adjustments.
Brand: BIESSE
Model: AKRON 1430
Type: Edge Banders
Year: 2016
Serial # 09745
BIESSE AKRON 1430A EDGEBANDER. --
Specifications: 0.4 - 3 mm Thickness coil edgebanding
.0.4 - 12 mm thickness of strips (HPL, veneer, solid wood strips)
Panel thickness minimum 10 mm and 60 mm maximum.
Minimum panel length 140 mm. (5.5")
Minimum panel width 85 mm (3.3)
Automatic strip & coil feed magazine with 3 mm PVC guillotine
Hot Melt glue system, 10 Minute heat-up time
1" Dia. Glue applicator roller; pressure section with (1) large dia. "non-stick" coated drive roller. Workstations
Front & Rear End Trims: (0.33 HP - 12,000 RPM motors)
Motors travel on (2) straight slides and pneumatic tilt 0° - 25° on horizontal plane
Top & Bottom Rough Trims with motors (0.75 HP - 12,000 RPM motors)
Digital readouts for easy setup
Top & Bottom Fine Trims with motors (0.5 HP - 12,000 RPM)
Top & Bottom Profile Scrapers with digital readouts for horizontal adjustments
Top & Bottom Glue Scrapers, digital readout for horizontal adjustments.
Elect./voltage:440 V, 60 Cy, 3 Ph.
Price as equipped new: $150,000
